Use applications
Selective micro-catheter for intravascular treatment such as TACE (Transcatheter Arterial Chemoembolization).
Product Details
Micro-catheter BISHOP
Feature
“Pencil Figure Tip”
Special tapered pencil figure tip improves selectivity.
“Ten Segments” shaft balance
Ten different stiffness from shaft to tip makes smooth advancement and improves pushability.
“Three Tip Shapes”
Three types of tips are available (straight, angle, double angle).
No need of manual shaping.
Catalog number
| Catalog Number | Effective Length |
Tip Shape |
Outer Diameter (Radiopaque Marker / Distal part / Proximal part) |
Inner Lumen (Distal / Proximal) |
Compatible Maximum Diameter of Guidewire |
Maximum Pressure (Open the Catheter Tip) |
|---|---|---|---|---|---|---|
| MC16-S110BY | 110cm | Straight | 0.645mm / 0.73mm / 0.93mm) (1.9Fr. / 2.2Fr. / 2.8Fr.) |
0.49mm /0.55mm (0.019inch / 0.022inch) |
0.46mm (0.018inch) | 6,895kPa (1,000 psi) |
| MC16-S130BY | 130cm | |||||
| MC16-A130BY | Angle | |||||
| MC16-D130BY | Double Angle | |||||
| MC16-S150BY | 150cm | Straight |
Product Information
Precautions
Please note that this website is intended to provide information on our company's products not for the public but for health care providers such as doctors, dentists, pharmacists, nurses and clinical technicians
